  11. Through-Beam Photoelectric Sensor Receiver, Bare Wire, Right Angle, Cylindrical, Selectable Light On/Dark On, NPN
Eaton Through-Beam Photoelectric Sensor Receiver, Bare Wire, Right Angle, Cylindrical, Selectable Light On/Dark On, NPN 12102A6513 - main

Through-Beam Photoelectric Sensor Receiver, Bare Wire, Right Angle, Cylindrical, Selectable Light On/Dark On, NPN

  • Mfr # 12102A6513

  • Zoro # G0628607

product price: $243.99
/ea
Free Shipping & Returns

Key Features

Width
3.46"
Depth
0.47"
Operating Temp. Range
-20 Degrees to 70 Degrees C
Electrical Connection
Bare Wire
Max. Sensing Distance
24m
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
12102A6513
Zoro #
G0628607
UPC #
-
Country of Origin
Mexico

Dimensions

Width
3.46"
Depth
0.47"
Diameter - Cylindrical Photoelectric Sensor
18 mm
Length - Cylindrical Photoelectric Sensor
66 mm
Diameter
18mm
Min. Object Size
Adjustable By Changing Gain
Length
2.60"
Cable Length
2 m
Overall Height
66 mm
Product Length/Depth
.47 in
Product Width
.71 in
Product Height
2.6 in
Sensor Diameter
18 mm
Overall Diameter
18 mm
Minimum Object Size
6.35mm Dia.
Overall Width
18 mm
Overall Depth
12 mm

Details

Item
Photoelectric Sensor Receiver
Operating Temp. Range
-20 Degrees to 70 Degrees C
Electrical Connection
Bare Wire
Max. Sensing Distance
24m
Body Material
Polyurethane
Footnotes
Use with Thru Beam Source 2UUT5
Light Source
Infrared LED
Response Time
10 msec
Max. Load Current
300 mA
Power Requirement - Cylindrical Photoelectric Sensor
20 to 264V AC/15 to 30V DC
Response Time (ms)
10
Operating Frequency
13 Hz
Max. Sensing Distance - Cylindrical Photoelectric Sensor
24 m
IP Rating
IP68, IP69K
Standards
CE, cUL Listed, UL Listed
Sensing Method
Through-Beam
Features
Latching Short Circuit
Power Requirement
20 to 264VAC/15 to 30VDC
Protection
Latching short circuit
Enclosure Material
Body: structural polyurethane foam
Maximum AC current
300 mA
Cable type
Polyvinyl Chloride (PVC)
Switch type
Photoelectric
Contact configuration
DC: NPN open collector
Input voltage
20-264 Vac, 15-30 Vdc
LED indicator
Output status: red
Maximum DC current
300 mA
Contact Rating
300 mA AC/DC at 20-264Vac/15-30Vdc
Compliances
CE Marked
Series
Comet
Sensing Distance - Minimum
30 mm
Sensing Distance - Maximum
24 m
Output Circuit Type
NPN
Load Current - Maximum
300 mA
Operating Temperature - Maximum
158 Degrees F
NEMA Enclosure Rating
1, 12, 13, 3, 4, 4X, 6, 6P
Style
Cylindrical
Operating Mode
Selectable Light On/Dark On
Operating Temperature - Minimum
-40 Degrees F
Orientation
Right Angle
Switching Frequency
13 Hz
Includes Indicator Lights
Indicator Lights Included
DC Voltage Rating
15-30V DC
AC Voltage Rating
20-264V AC
Electrical Installation Type
Prewired Cable
Emitted Sensor Light
Red Light

Description

Photoelectric Sensor Receiver, Sensing Method - Cylindrical Photoelectric Sensor Through Beam Receiver, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 20 to 264V AC/15 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 6 ft. Cable, Circuit Type - Cylindrical Photoelectric Sensor NPN, Max. Sensing Distance - Cylindrical Photoelectric Sensor 24 m
