1 Square Recessed Oak Pull Down
Mfr # E1L22F30B
Zoro # G704081982
product price:
$
98.91
/ea
Key Features
Voltage
12V AC
Lamp Type - Fixtures
LED
Color Temperature
3000 K
Lumens
650 lm
Dimmable
Yes
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- E1L22F30B
- Zoro #
- G704081982
- UPC #
- 633999014651
- Country of Origin
- China
Details
- Voltage
- 12V AC
- Lamp Type - Fixtures
- LED
- Color Temperature
- 3000 K
- Lumens
- 650 lm
- Dimmable
- Yes
- Beam Angle
- 38°
- Max. Fixture Wattage
- 6.1 W
- Housing Finish
- Black
Description
Small aperture 12V AC Downlight delivers over 600 lumens. More than a traditional 50W MR16 Halogen Lamp. Requires 12V AC Transformer (daisy chain up to 6). Dimmable ELV, MLV or 0-10V depending on transformer used.
- Requires 12V AC transformer. Dimmable ELV, MLV or 0-10V depending on transformer used.
- IC for use with direct contact to insulation
- Height allows for use in ceilings with under 4 depth. Ceiling thickness can be reduced from fixture depth.
- Daisy chain up to 6 fixtures with E1LDRV60
- 28°, 38° and 50° beam options, not reccomended for in field changes.
- Remodel requires no frame. New construction E1LF2 frame available.
- UL Damp Location Rated
- UL Listed, Meets California Title 24 JA8-2016-E and Energy Star standards.
- Life Span 50,000 Hours L70
