RC104, 11.2 ton Capacity, 4.13 in Stroke, General Purpose Hydraulic Cylinder

Mfr # RC104
Zoro # G1098666

1,117.99

Free Shipping & Returns

Zoro's best price: not eligible for any other offers or promotions

Key Features

Center Hole Dia.

1 1/2 in

Body Material

Steel

Retracted Height

6.75 in

Extended Height

10.33 in

Weight Capacity

10 tons

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: RC104
Zoro #: G1098666
UPC #: 662005300808
Country of Origin: China

Dimensions

Center Hole Dia.: 1 1/2 in
Retracted Height: 6.75 in
Extended Height: 10.33 in
Plunger Thread Size: 1"-8
Bolt Circle Dia.: 1.56"
Outside Dia.: 2.25 in
Plunger Dia.: 1.5 in
Stroke Length: 4 1/8 in
Thread Size: 5/16"-18
Collar Thread Size: 2-1/4"-14
Base Bolt Circle Dia.: 1.56 in
Nominal Stroke Length: 4 in

Details

Body Material: Steel
Weight Capacity: 10 tons
Includes: Coupler, Dust Cap
Single Acting/Double Acting: Single Acting
Handle: No
Max. Pressure: 10,000 psi
Effective Area: 2.25 sq. in.
Oil Capacity: 9.23 cu. in.
Item: Hydraulic Ram
Cylinder Type: General Purpose
Effective Push Area: 2.24 sq in
Series: RC
Nominal Capacity: 10 ton
Oil Capacity Push: 9.23 cu in
Max. Push Capacity: 10 ton
Finish: Paint
Type: General Purpose

Description

Hydraulic Ram, Single Acting, General Purpose, Steel, Nominal Capacity 10 ton, Max. Push Capacity 10 ton, Stroke Length 4 1/8 in, Nominal Stroke Length 4 in, Effective Push Area 2.24 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 9.23 cu in, Retracted Height 6.75 in, Extended Height 10.33 in, Outside Dia. 2.25 in, Plunger Dia. 1.5 in, Plunger Thread Size 1 In.-8, Collar Thread Size 2-1/4 In.-14, Base Bolt Circle Dia. 1.56 in, Center Hole Dia. 1 1/2 in, Series RC, Includes Coupler, Dust Cap
