  11. Strobe Light, Clear, Xenon, 24V DC, 60 FPM, Not Applicable Dia., Surface
Federal Signal Strobe Light, Clear, Xenon, 24V DC, 60 FPM, Not Applicable Dia., Surface G-STR-024-D-C - main

Strobe Light, Clear, Xenon, 24V DC, 60 FPM, Not Applicable Dia., Surface

  • Mfr # G-STR-024-D-C

  • Zoro # G5578030

product price: $728.99
/ea
Free Shipping & Returns

Key Features

Lamp Type
Xenon
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
Flashes per Minute
60
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
G-STR-024-D-C
Zoro #
G5578030
UPC #
782979234104
Country of Origin
United States

Dimensions

Height
8 61/64 in
Depth
5 15/64 in
Width
5 15/64 in
Overall Length
5 7/32 in
Overall Width
5 7/32 in
Footprint Length
5 1/4 in
Footprint Width
5 1/4 in
Overall Depth
8 15/16 in

Details

Item
Strobe Light
Color
Clear
Lamp Type
Xenon
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
Flashes per Minute
60
Housing Material
Glass Reinforced Polyester
Standards
ABS, ATEX Ex d IIC Ex de IIC and Ex tb IIIC, CE, CSFM Approved, cUL Listed, EAC, IECEx, INMETRO, UKEX Certified, UL Listed
Features
Corrosion Resistant, M20 Entries Standard
Voltage
24V DC
Includes
Dome Guard
Operating Temp.
-58 Degrees to 158 Degrees F
Rating
IP66
Mounting
Surface
Current Drawn
1.50A DC
Light Output
21 Joules
Lens Design
Fresnel
For Use With
Control Panel, Security, Industrial, Marine, Signaling System
Product Type
Strobe Light
Audible Alarm Type
Visual
Connection Type
TermiN/Al Block
NEMA Rating
NEMA 4X
For Hazardous Location
Class I, Division 2, Class II, Division 2
Housing Color
Black
Light Source
Xenon
Light Operating Mode
Strobe
Operating Temperature - Maximum
158 Degrees F
Light Intensity
500 cd
Control Protocol
User Operated
Brightness Selection
Fixed Brightness
Lens Shape
Dome
Operating Temperature - Minimum
-67 Degrees F
Mounting Mechanism
Screw
Lifespan
10,000 hr
Mounting Style
Surface Mount
Lens Color
Clear
IP Rating
IP66, IP67, IP69K
Footprint Shape
Square
Requires Base
Base Not Required
Operating Current
0.830 A @ 24V DC
Includes Mounting Hardware
Mounting Hardware Included
Operating Voltage
24V DC

Description

Strobe Light, Color Clear, Lamp Type Xenon, Flashes per Minute 60, Light Output 21 Joules, Lamp Life 10,000 hr, Lens Design Fresnel, Lens Material Polycarbonate, Housing Material Glass Reinforced Polyester, Mounting Surface, Operating Temp. -58 Degrees to 158 Degrees F, Rating IP66, Power Source Wire, Current Drawn 1.50A DC, Width 5 15/64 in, Depth 5 15/64 in, Height 8 61/64 in
