Hand Operated Drump Pump, Rotary, 10 GPM

Fill-Rite Hand Operated Drump Pump, Rotary, 10 GPM FR150
Tap to zoom
Hover or click to zoom
Feedback Help us improve our product images
$144.99
  • Action Type: Lever
  • For Media Type: Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oil, Kerosene, Motor Oil, Stoddard Solvent
  • For Container Size: 55 gal
See full product details
This item ships free.
Total: $144.99

Fill-Rite #FR150 Specifications

  • Action Type: Lever
  • For Media Type: Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oil, Kerosene, Motor Oil, Stoddard Solvent
  • For Container Size: 55 gal
  • Max. Flow Rate: 25 oz per stroke
  • Max. Viscosity: 50 SUS
  • Wetted Materials: Aluminum, Buna-N, Delrin(R)
  • Food Grade: No
  • Max. Fluid Temp.: 150 Degrees F
  • Discharge Tube Outlet ID: 3/4 in
  • Includes: Pump Only
  • Metered: No
  • Discharge Tube Outlet OD: 7/8 in
  • Includes Suction Tube: No
  • Runs Dry: Yes
  • Diesel Exhaust Fluid Compatible: No
  • Overall Width: 10
  • Transfer Pump Application: Agriculture, Construction, Farming
  • Standards: UL Listed
  • Self-Priming: Yes
  • Pressure Range: 38 psi
  • Agency Compliance: UL/cUL
  • Seal Material: BUNA-N
  • Seal Type: Mechanical
  • Outlet Size: 3/4" NPT
  • Bypass Valve: No
  • Ounces per Stroke: 25 oz.
  • Height: 19-3/4"
  • Discharge Size FPT (In.): 3/4
  • Item: Hand Operated Drum Pump
  • Width: 10"
  • Pump Mount Size: 2"
  • Max. Pressure: 38 psi
  • GPM: 10
  • Overall Length: 6
  • Manufacturers Warranty Length: 2 yr.
  • Inlet Size: 1" NPT
  • For Use With: Diesel/Fuel Oil
  • Features: Anti-Siphon Valve, Can Be Used to Pump In Reverse Direction, Piston Hand Pump
  • Max. Liquid Temp.: 150 Degrees F
  • Housing Material: Aluminum
  • Overall Height: 19-3/4"
  • Piston Material: Aluminum
  • Pump Design: Rotary Vane
  • Max. Head: 6 ft.
  • Length: 6"
  • Adapter Material: Cast Iron
  • For Container Type: Drum
  • Housing Material - Pumps: Cast Iron
  • Spout Material: Aluminum
  • Pump Connection OD: 2 1/8 in
  • Not Recommended Chemicals: Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Ammonia (Liquids), Ammonium Hydroxide, Anhydrous Ammonia, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Cyclohexane, DEF, Deionized Water, Ethyl (Ethanol), Ethyl Acetate, Fertilizers, Formic Acid, Fresh Water, Fungicides, Heptane, Herbicides, Hexane, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Isopropyl (Isopropanol), Lacquer Thinners, Lithium Grease, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sodium Hypochlorite/Bleach (to 20%), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Trichlorethylene (50%), Turpentine, Windshield Washer Fluid, Xylene
  • Series: 5200 SERIES, PISTON HAND PUMPS
  • Power Source: Hand Operated
  • Spout Connection Size: 3/4 in
  • Includes Bung Adapter: Yes
  • Pump Connection ID: 2 in
  • Height Above Container: 19 1/2 in
  • Includes Discharge Hose: No
  • Max. Head Pressure: 50 psi
  • Max. Head - Pumps: 6 ft
  • Spout Length: 3 in
  • Includes Spout: Yes
  • Max. Oil Flow: 25 oz per stroke
  • Compatible Chemicals: Antifreeze (Coolant), Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Kerosene, Motor Oil, Stoddard Solvent (Mineral Spirits)
  • Bung Connection Dia.: 2 in
  • Includes Nozzle: No
  • Min. Operating Temp.: 0 Degrees F
  • Discharge Connection Type: FNPT
  • Max. Outlet Pressure: 50 psi
  • Gear Lube: NT
  • Grease: NT
  • Adapter Connection Type: MNPT
  • Country of Origin (subject to change): United States
Feedback Help us improve our product information

Description

Hand Operated Drum Pump, Action Type Piston, Wetted Materials Aluminum, Buna-N, Delrin(R), Seal Material BUNA-N, Piston Material Aluminum, GPM 10, Max. Pressure 38 psi, Ounces per Stroke 25 oz., Max. Viscosity 50 SUS, Inlet Size 1 In. NPT, Outlet Size 3/4 In. NPT, Overall Length 6, Metered No, Adapter Material Cast Iron, Features Anti-Siphon Valve, Can Be Used to Pump In Reverse Direction, Piston Hand Pump, Standards UL Listed
