  9. Ultrasonic Level Switch, Side Mt, Polypro
Flowline Ultrasonic Level Switch, Side Mt, Polypro AU13-1120 - main

Ultrasonic Level Switch, Side Mt, Polypro

  • Mfr # AU13-1120

  • Zoro # G4230527

product price: $754.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
120/240V AC
Contact Rating
250V AC @ 16 A
Mounting
3/4 in NPT
Height
4.3
Material
polypropylene
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AU13-1120
Zoro #
G4230527
UPC #
638845442572
Country of Origin
United States

Dimensions

Height
4.3
Width
2.8
Length
8.0
Overall Length
4.7 in
Float Length
4 3/4 in
Connection Size
3/4 in
Float Diameter
1 in

Details

Input Voltage
120/240V AC
Contact Rating
250V AC @ 16 A
Mounting
3/4 in NPT
Item
Ultrasonic Level Switch
Material
polypropylene
Standards
EN 61010-1, EN 61326 EMC, LR 79326-3
Type
Point Level Sensor with Controller
Repeatability
+/-0.5mm in Water
Output
Relay
Temp. Range
F: -40 Degrees to 176 Degrees C: -40 Degrees to 80 Degrees
Contact Type
SPDT Relay
Orientation
Side Mounted
Sensor Rating
General Purpose
Accuracy
+/-1 mm
Max. Pressure
150 psi @ 25 Degrees C
Body Material
Polypropylene
Probe Material
Polypropylene
Product Type
Liquid Level Switch
Mounting Orientation
Horizontal
Nameplate Voltage
120/240V AC
Enclosure Rating
NEMA 4
Number of Outputs - Analog
1
Connection Type
NPT
Stem Material
Polypropylene
For Media Type
Corrosive Liquids
Media Temperature - Maximum
176 Degrees F
Float Material
Polypropylene
Output Wire Configuration
4-Wire
Operating Pressure - Maximum
150 psi
Number of Outputs - Digital
1

Description

Ultrasonic Level Switch, Product Type Liquid Level Switch, Connection Size 3/4 in, For Media Type Corrosive Liquids, Connection Type NPT, Body Material Polypropylene, Accuracy +/-1 mm, Range Not Applicable, Stem Length Not Applicable, Operating Pressure - Maximum 150 psi, Media Temperature - Maximum 176 Degrees F, Mounting Orientation Horizontal, Enclosure Rating NEMA 4, Number of Outputs - Analog 1, Float Diameter 1 in, Number of Outputs - Digital 1, Float Length 4 3/4 in

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
