  5. Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 153 mm Full Color LCD with Fast Update Rate
Fluke Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 153 mm Full Color LCD with Fast Update Rate FLUKE-190-504/FPC - main

Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 153 mm Full Color LCD with Fast Update Rate

  • Mfr # FLUKE-190-504/FPC

  • Zoro # G707630675

product price:  $8,551.99
/ea
Free Shipping & Returns

Key Features

Bandwidth (MHz)
500 MHz
Channels
4
Display
153 mm Full Color LCD with Fast Update Rate
FFT Analysis
Frequency Spectrum Using FFT Analysis
Safety Rating
CAT III 1000V / CAT IV 600V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FLUKE-190-504/FPC
Zoro #
G707630675
UPC #
754082155294
Country of Origin
Romania

Dimensions

Bandwidth (MHz)
500 MHz
Manufacturers Warranty Length
1 yr (Battery and Accessories), 3 yr (Main Instrument)
Display Screen Length
5.2 in
Display Screen Width
3.5 in
Memory Depth
30,000 Data Points Per Channel
Bandwidth
500 MHz

Details

Item
Handheld Oscilloscope
Channels
4
Display
153 mm Full Color LCD with Fast Update Rate
FFT Analysis
Frequency Spectrum Using FFT Analysis
Safety Rating
CAT III 1000V / CAT IV 600V
True RMS
Yes
Features
Advanced Automatic Measurements, Power (VPWM, VA, W, PF) and Time (mAs, V/s, w/s), Connect-and-View(TM) Continuous Auto-Trigger, Single Shot, Pulse Width and Video Triggering, IP-51 Rated for Dust and Drip Proof to Withstand Harsh Environments, TrendPlot, Trend Measurement Readings for up to 22 days
Battery Type
Li-Ion
Persistence
Digital Persistence Off/Short/Medium/Long/Infinite and Envelope Mode
Glitch Capture
8 ns
Sampling Rate
125 MS/s
Waveform / Measurement Stored
Measurement Data is Initially Stored in RAM, which is Maintained by the Main Battery with a 30 Seconds Back-up when Battery is Exchanged
Includes
(4) TRM50 Cable Terminators, (4) VPS410-II Probes, AC Power Adapter, Carrying Case, DWA-131 Wi-Fi Dongle, Hand Strap, Hanging Strap, Power Cord, USB Cable
Interface
USB
Triggering Mode
Auto
Battery Life
7 hr
Real Time Clock
Yes
Input Sensitivity
2 mV to 100 V/div
AC Magnitude Calculation
True RMS
Calibration Certificate Type
Not Certified
Includes Batteries
Batteries Included
Standards
EN 61010-1, IEC 61010-2-030: CAT IV 600V/CAT III 1000V
Time Base - Minimum
1 nsec/div
Channel Source Isolation
Fully Isolated
Battery Run Time
7 hr
AC Voltage Measurement - Maximum
1,100 V
Number of Channels
4
Digital Display Screen Type
LCD
Battery Chemistry
Lithium Ion
Basic AC Voltage Accuracy
+/-(1.50% +10 Counts)
IP Rating
IP51
CAT Safety Rating
CAT III 1000V, CAT IV 600V
Input Sensitivity - Maximum
100 V/div
Basic DC Voltage Accuracy
+/-(1.50% +6 Counts)
Time Base - Maximum
4 sec/div
Body Style
Handheld
AC Voltage Measurement Resolution
100 mV
Input Sensitivity - Minimum
100 V/div
AC Voltage Measurement - Minimum
500 mV
Power Source
Battery

Description

Handheld Oscilloscope, Bandwidth (MHz) 500 MHz, 4 Channels, 153 mm Full Color LCD with Fast Update Rate Display, True RMS Yes, Sampling Rate 125 MS/s, Measurement Data is Initially Stored in RAM, which is Maintained by the Main Battery with a 30 Seconds Back-up when Battery is Exchanged Waveform / Measurement Stored, FFT Analysis Frequency Spectrum Using FFT Analysis, Real Time Clock Yes, Auto Triggering Mode, Input Sensitivity 2 mV to 100 V/div

Restrictions

Hazardous material
