Shop FLUKE

Pressure Calibrator, -12 to 36 psi

  • Mfr # FLUKE-719 30G
  • Zoro # G8320611
product price:
$
5,160.99
/ea
Free Shipping & Returns
Zoro's best price: not eligible for any other offers or promotions

Key Features

Includes
Alligator Clips, Hose Kit, Protective Yellow Holster, Test Leads
Display
Multiline LCD
Standards
CSA C22.2 No. 1010.1:1992, EMC EN50082-1: 1992, EMC EN55022: 1994 Class B
Loop Supply Voltage
24V DC
Powered By
(2) 9V Alkaline Batteries
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
FLUKE-719 30G
Zoro #
G8320611
UPC #
095969465366
Country of Origin
China

Dimensions

Manufacturers Warranty Length
3 yr
Battery Size
9V

Details

Item
Handheld Pressure Calibrator
Includes
Alligator Clips, Hose Kit, Protective Yellow Holster, Test Leads
Display
Multiline LCD
Standards
CSA C22.2 No. 1010.1:1992, EMC EN50082-1: 1992, EMC EN55022: 1994 Class B
Loop Supply Voltage
24V DC
Powered By
(2) 9V Alkaline Batteries
Current Measurement Range
0 to 24mA DC
Displayed Pressure Units
bar, cm wc, in Hg, in wc, kg/sq cm, kPa, mbar, mm Hg, psi
Source Current
4 to 20mA
Internal Pressure Range Accuracy
+/-0.035% of Full Scale
Pressure Source
Internal Electric Pump
Measurement Functions
mA DC, Pressure
Calibration Certificate
NIST
Internal Pressure Measurement Range
-12 to 36 psi
Pressure Modules
750P Series (50 Ranges)
Internally Generated Pressure Range
0 to 30 psi
Pressure Range with External Modules
1 in wc to 10,000 psi
Pressure Measuring Units
bar, mbar, psi
Voltage Measurement - Minimum
0 V DC
Source Current - Minimum
0 mA
Digital Display Screen Type
LCD
Voltage Measurement - Maximum
24 V DC
Current Measurement - Minimum
0 mA
Parameters Sourced
AC Current, DC Current, Pressure
Number of Batteries Required
1
Pressure Measurement - Maximum
36 psi
Pressure Measurement - Minimum
-12 psi
Pressure Measurement Accuracy
0.025% (6 Months); 0.035% (1 Year)
Communication Protocol
HART
Includes Batteries
Batteries Included
Battery Chemistry
Alkaline
Source Current - Maximum
24 mA
Intrinsic Safety
Not Specified Intrinsically Safe
Parameters Measured
AC Current, DC Current, Pressure
Calibration Certificate Type
NIST
Current Measurement - Maximum
24 mA

Description

Handheld Pressure Calibrator, Internal Electric Pump Pressure Source, Measurement Functions mA DC, Pressure, Internal Pressure Measurement Range -12 to 36 psi, Internally Generated Pressure Range 0 to 30 psi, Pressure Range with External Modules 1 in wc to 10,000 psi, Loop Supply Voltage 24 V DC, Current Measurement Range 0 to 24mA DC, Source Current 4 to 20mA, Display Multiline LCD, Standards CSA C22.2 No. 1010.1:1992, EMC EN50082-1: 1992, EMC EN55022: 1994 Class B, Calibration Certificate NIST
