13 to 220 Watts, 1, 2, 3, or 4 Lamps, Electronic Ballast

  • Mfr # WH7-120-L

  • Zoro # G9123161


product price: $57.75
/ea

Key Features

Ballast Lamp Type
Compact Fluorescent, 2D, T5, T5HO, T6, T8, T8HO, T9, T10HO, T12, T12HO
Ballast Max. Number of Lamps
4
Input Voltage
120V AC
Ballast Voltage
120
Ballast Start Type
Instant
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
WH7-120-L
Zoro #
G9123161
UPC #
872180100845
Country of Origin
China

Dimensions

Width
1 3/4 in
Height
1 in
Length
19 1/4 in

Details

Ballast Lamp Type
Compact Fluorescent, 2D, T5, T5HO, T6, T8, T8HO, T9, T10HO, T12, T12HO
Item
Fluorescent Ballast
Ballast Max. Number of Lamps
4
Input Voltage
120V AC
Ballast Voltage
120
Ballast Start Type
Instant
Ballast Dimming
No
Ballast Item
Electronic Ballast
Ballast Max. Lamp Watts
220
Ballast Type
Electronic
Ballast Dimming Type
No Dimming
Input Watts
39 to 242 W
Ballast Family
WorkHorse
Number of F40T12 U-Bend Lamps
3 or 4
Power Factor
Greater Than 0.98
Number of F48T12 Lamps
1 or 2
Number of F42/F48T12 Lamps
1 or 2
Number of F72T12 Lamps
3
Number of F25T12 Lamps
3 or 4
Number of F80T5 Lamps
2
Amps AC
2.1 A
Ballast Lamp Watts
220
Number of F42/F48T12 Lamps
1 or 2
Number of F20T12 Lamps
4
Number of FC12T5 Lamps
3 or 4
Total Harmonic Distortion
32 %
Number of F54T5 Lamps
3 or 4
Number of F40T12 Lamps
3 or 4
Number of F30T12 Lamps
3 or 4
Number of F58T8 Lamps
3
Number of F96T12 Lamps
3
Number of F24/F36T12 Lamps
3 or 4
Number of F34T12 Lamps
3 or 4
Light Output
Normal
Number of F50BX Lamps
3 or 4
Number of F60T8 Lamps
3
Number of F55BX Lamps
2 or 3
Number of F48T8 Lamps
3 or 4
Number of F39T5 Lamps
4
Number of F40BX Lamps
3 or 4
Number of F60T12 Lamps
1 or 2
Min. Starting Temp.
-22 Degrees F
Number of F13T8 Lamps
4
Number of F60/F64T12 Lamps
3 or 4
Number of F64T12 Lamps
1 or 2
Number of F60/F64T12 Lamps
1 or 2
Number of F24/F36T12 Lamps
3 or 4
Ballast Factor
1.17
Wiring Type
Parallel
Voltage
120
Standards
ANSI C82.11-1994, FCC Part 18-A, UL Listed
Fixture Ballast Type
Electronic
Ballast Bulb Type
T12, T5, T8
Dimming Type
No Dimming
Starter Required
No
Thermal Protection
Class P
Brand and Series
WorkHorse
Sockets Included
No
Number of F14T12 Lamps
4
Number of F36T12 Lamps
1 or 2
Number of F42T12 Lamps
1 or 2
Dimming Method
No Dimming
Dimming Range
No Dimming
Frequency
50/60 Hz
Number of F30T8 Lamps
4
Max. Bulb Watts
13 W, 14 W, 20 W, 24 W, 25 W, 30 W, 39 W, 44 W, 45 W, 55 W, 58 W, 80 W, 85 W
Operating Amps @ 120V
2.16 A
Number of F24T12 Lamps
1
Number of Bulbs Supported
1, 2, 3, 4
Dimming
No
Hz
50/60
Lamp Types Supported
(1) F24T12, (2) F80T5, (3 or 4) F24T12, (3 or 4) F25T12, (3 or 4) F36T12, (3 or 4) F48T8, (3) F58T8, (3) F60T8, (3) F72T12, (3) F96T12, (4) F13T8, (4) F14T12, (4) F20T12, (4) F30T8, (4) F39T5

Description

WorkHorse, Electronic, Fluorescent Ballast, Ballast Start Type Instant, Input Voltage 120V AC, Number of Bulbs Supported 1, 2, 3, 4, Max. Bulb Watts 13 W, 14 W, 20 W, 24 W, 25 W, 30 W, 39 W, 44 W, 45 W, 55 W, 58 W, 80 W, 85 W, Ballast Bulb Type T12, T5, T8, Dimming No, Dimming Type No Dimming, Dimming Method No Dimming, Dimming Range No Dimming, Min. Starting Temp. -22 Degrees F

Restrictions

WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
