Carbide Turning Insert, Diamond, CCMT060202, for Stainless Steel
Mfr # 260050 HB7140-2
Zoro # G514821839
product price: $9.19
/eaSold in multiples of 10 for $91.90
Key Features
Insert Thickness
1.5 mm
Insert Style
CCMT
Cutting Conditions
Heavily Interrupted
Insert Application
Finishing
Max. Cutting Depth (ap max)
2 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
260050 HB7140-2
Zoro #
G514821839
UPC #
-
Country of Origin
Japan
Dimensions
Insert Thickness
1.5 mm
Max. Cutting Depth (ap max)
2 mm
Insert Size
60202
Corner Radius
0.2 mm
Min. Cutting Depth (ap min)
0.15 mm
Cutting Depth
0.2 mm
Details
Insert Style
CCMT
Cutting Conditions
Heavily Interrupted
Insert Application
Finishing
Item
Indexable Insert for Turning
Grade
HB7140-2
Tolerance
Stainless Steel
Chip-Breaker
VS
Inscribed Circle
2
Insert Shape
80 Degrees Diamond
Insert Material
Carbide
Workpiece Material
Stainless Steel
No. of Edges
2
ISO Number
CCMT 060202
Coating
coated
Description
CC.T 060202 HB7140-2 Grade: HB7140-2 Chip breaker: VS Tolerance: M Cutting depth ap: 0.2 2.5 mm Feed f: 0.1 0.3 mm/rev. Cutting speed vc main application: 70 230 m/min
