Carbide Turning Insert, Parallelogram, ZCMX10T308, for Steel
Mfr # 268438 HBZ025
Zoro # G514821594
product price:Â $18.29
/ea
Sold in multiples of 10 for $182.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Insert Size
10T308
Grade
HBZ025
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- 268438 HBZ025
- Zoro #
- G514821594
- UPC #
- -
- Country of Origin
- Austria
Dimensions
- Insert Size
- 10T308
- Corner Radius
- 0.4 mm
- Suitable Tool Diameter
- 18 mm
- Cutting Depth
- 0.4 mm
- Insert Thickness
- 2.5 mm
- Max. Cutting Depth (ap max)
- 3.5 mm
- Min. Cutting Depth (ap min)
- 0.55 mm
Details
- Item
- Indexable Insert for Turning
- Insert Shape
- Parallelogram
- Insert Style
- ZCMX
- Inscribed Circle
- 10 mm
- Grade
- HBZ025
- Insert Material
- Carbide
- ISO Number
- ZCMX 10T308
- Cutting Conditions
- Continuous
- Coating
- PVD
- No. of Edges
- 2
- Workpiece Material
- Steel
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. Suitable for: Boring tool No. 268463 268468, size 8. suitable for tool dia. Dc: 18 mm Grade: HBZ025 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 90 210 m/min
