Carbide Turning Insert, Parallelogram, ZCMX050204, for Steel
Mfr # 268420 HBZ035
Zoro # G414822721
product price: $17.45
/ea
Sold in multiples of 10 for $174.50
Key Features
Cutting Conditions
Slightly Interrupted
Cutting Depth
0.4 mm
Min. Cutting Depth (ap min)
0.25 mm
ISO Number
ZCMX 050204
Coating
PVD
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268420 HBZ035
Zoro #
G414822721
UPC #
-
Country of Origin
Austria
Dimensions
Cutting Depth
0.4 mm
Min. Cutting Depth (ap min)
0.25 mm
Insert Thickness
1.5 mm
Corner Radius
0.4 mm
Insert Size
50204
Suitable Tool Diameter
10 mm
Max. Cutting Depth (ap max)
1.75 mm
Details
Cutting Conditions
Slightly Interrupted
ISO Number
ZCMX 050204
Coating
PVD
No. of Edges
2
Item
Indexable Insert for Turning
Inscribed Circle
5 mm
Insert Material
Carbide
Insert Style
ZCMX
Workpiece Material
Steel
Insert Shape
Parallelogram
Grade
HBZ035
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 10 mm Grade: HBZ035 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 50 190 m/min
