Carbide Turning Insert, Parallelogram, ZCMX070304, for Steel
Mfr # 268439 HBZ035
Zoro # G014821476
product price:Â
$
19.39
/ea
Sold in multiples of 10 for $193.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
7 mm
Insert Size
70,304
Grade
HBZ035
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 268439 HBZ035
- Zoro #
- G014821476
- UPC #
- -
- Country of Origin
- Austria
Dimensions
- Insert Size
- 70,304
- Corner Radius
- 0.4 mm
- Insert Thickness
- 2 mm
- Suitable Tool Diameter
- 14 mm
- Min. Cutting Depth (ap min)
- 0.4 mm
- Cutting Depth
- 0.4 mm
- Max. Cutting Depth (ap max)
- 1.75 mm
Details
- Item
- Indexable Insert for Turning
- Insert Shape
- Parallelogram
- Insert Style
- ZCMX
- Inscribed Circle
- 7 mm
- Grade
- HBZ035
- Insert Material
- Carbide
- Insert Application
- Finishing
- ISO Number
- ZCMX 070304
- No. of Edges
- 2
- Coating
- coated
- Cutting Conditions
- Slightly Interrupted
- Workpiece Material
- Steel
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 14 mm Grade: HBZ035 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 50 190 m/min
