Carbide Turning Insert, Parallelogram, ZCMX080308, for Steel
Mfr # 268427 HBZ035
Zoro # G214821856
product price:Â $18.29
/ea
Sold in multiples of 10 for $182.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
8 mm
Insert Size
80,308
Grade
HBZ035
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
268427 HBZ035
Zoro #
G214821856
UPC #
-
Country of Origin
Austria
Dimensions
Insert Size
80,308
Corner Radius
0.8 mm
Max. Cutting Depth (ap max)
2.75 mm
Cutting Depth
0.4 mm
Suitable Tool Diameter
16 mm
Min. Cutting Depth (ap min)
0.55 mm
Insert Thickness
2 mm
Details
Item
Indexable Insert for Turning
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
8 mm
Grade
HBZ035
Insert Material
Carbide
ISO Number
ZCMX 080308
Coating
PVD
Cutting Conditions
Slightly Interrupted
Workpiece Material
Steel
No. of Edges
2
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 16 mm Grade: HBZ035 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 50 190 m/min
