Carbide Turning Insert, Parallelogram, ZCMX10T304, for Steel
Mfr # 268433 HBZ025
Zoro # G314821879
product price:Â $18.89
/ea
Sold in multiples of 10 for $188.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Insert Size
10T304
Grade
HBZ025
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
268433 HBZ025
Zoro #
G314821879
UPC #
-
Country of Origin
Austria
Dimensions
Insert Size
10T304
Corner Radius
0.4 mm
Max. Cutting Depth (ap max)
2 mm
Insert Thickness
2.5 mm
Min. Cutting Depth (ap min)
0.4 mm
Suitable Tool Diameter
20 mm
Cutting Depth
0.4 mm
Details
Item
Indexable Insert for Turning
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Grade
HBZ025
Insert Material
Carbide
Insert Application
Finishing
ISO Number
ZCMX 10T304
Workpiece Material
Steel
Cutting Conditions
Continuous
No. of Edges
2
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 20 mm Grade: HBZ025 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 90 210 m/min
