Carbide Turning Insert, Parallelogram, ZCMX10T308, for Aluminum
Mfr # 268438 HUZ310
Zoro # G714821547
product price:Â
$
20.89
/ea
Sold in multiples of 10 for $208.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
10 mm
Insert Size
10T308
Grade
HUZ310
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 268438 HUZ310
- Zoro #
- G714821547
- UPC #
- -
- Country of Origin
- Austria
Dimensions
- Insert Size
- 10T308
- Corner Radius
- 0.4 mm
- Insert Thickness
- 2.5 mm
- Cutting Depth
- 0.2 mm
- Suitable Tool Diameter
- 18 mm
- Max. Cutting Depth (ap max)
- 275 mm
- Min. Cutting Depth (ap min)
- 15 mm
Details
- Item
- Indexable Insert for Turning
- Insert Shape
- Parallelogram
- Insert Style
- ZCMX
- Inscribed Circle
- 10 mm
- Grade
- HUZ310
- Insert Material
- Carbide
- ISO Number
- ZCMX 10T308
- Cutting Conditions
- Continuous
- Coating
- Uncoated
- Workpiece Material
- Aluminum
- No. of Edges
- 2
Description
Suitable for: Boring tool No. 268463 268468, size 8. suitable for tool dia. Dc: 18 mm Grade: HUZ310 Cutting depth ap: 0.2 4 mm Feed rate f when turning: 0.05 0.4 mm Feed rate f when drilling: 0.03 0.3 mm Cutting speed vc main application: 200 600 m/min
