Carbide Turning Insert, Diamond, CC.T060202, for Stainless Steel
Mfr # 260084 HBT130
Zoro # G714821462
product price: $9.45
/eaSold in multiples of 10 for $94.50
Key Features
No. of Edges
2
Min. Cutting Depth (ap min)
0.25 mm
Insert Material
Carbide
Corner Radius
0.4 mm
Cutting Conditions
Slightly Interrupted
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
260084 HBT130
Zoro #
G714821462
UPC #
-
Country of Origin
Korea, Republic of
Dimensions
Min. Cutting Depth (ap min)
0.25 mm
Corner Radius
0.4 mm
Insert Thickness
1.5 mm
Max. Cutting Depth (ap max)
2 mm
Insert Size
60202
Cutting Depth
0.1 mm
Details
No. of Edges
2
Insert Material
Carbide
Cutting Conditions
Slightly Interrupted
Inscribed Circle
2
Workpiece Material
Stainless Steel
Insert Shape
80 Degrees Diamond
Insert Application
Finishing
ISO Number
CC.T 060202
Grade
HBT130
Chip-Breaker
Stainless Steel
Insert Style
CC.T
Coating
TiCN
Item
Indexable Insert for Turning
Description
CCMT 060204 HBT130 Grade: HBT130 Chip breaker: M Cutting depth ap: 0.1 1 mm Feed f: 0.05 0.2 mm/rev. Cutting speed vc main application: 60 220 m/min
