  15. 1NC/1NO Safety Interlock Switch Nema 1, 12, 13 IP 66, 67
Honeywell 1NC/1NO Safety Interlock Switch Nema 1, 12, 13 IP 66, 67 GKMB33 - main

1NC/1NO Safety Interlock Switch Nema 1, 12, 13 IP 66, 67

  • Mfr # GKMB33

  • Zoro # G3967677

product price: $404.99
/ea
Free Shipping & Returns

Key Features

Style
Actuating Key
Series
GKM
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
1NO/1NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GKMB33
Zoro #
G3967677
UPC #
-
Country of Origin
China

Dimensions

Height
2.75 in
Width
1.34 in
Depth
0.63 in
Cable Length
9.8 ft
Overall Height
2.73 in
Overall Depth
0.63 in
Overall Width
1.34 in

Details

Item
Safety Interlock Switch
Style
Actuating Key
Series
GKM
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
1NO/1NC
Connection Type
9.8 ft Dead End Cable
IP Rating
IP66, IP67
Operating Temp. Range
-13 Degrees to 185 Degrees F
Description/Special Features
1,000,000 Expected Mechanical Operational Life, Bottom Exit Cable, Fully Sealed Construction
Standards
CE, CSA, EN60529, UL Listed
NEMA Rating
1, 12, 13
Contact Material
Silver
Body Material
Plastic
Features
Red Switch Body
Electrical Connection
4 Pin M12
Operating Temperature - Maximum
185 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Actuator Material
Stainless Steel
Hazardous Location Specification
Not Rated
Actuating Key Type
90 Degrees , Pivoting, Flat
Key Hole Location
Front, Top
Circuitry Action
Slow Action
Includes Actuating Key
No Actuating Key Included
NEMA Enclosure Rating
1, 12, 13

Description

Safety Interlock Switch, Actuating Key, Contact Form 1NO/1NC, Connection Type 9.8 ft Dead End Cable, AC Contact Rating 10 A, Series GKM, DC Contact Rating 0.1 to 10 A @ 250 V, Solenoid Voltage Not Applicable, Height 2.75 in, Width 1.34 in, Depth 0.63 in, NEMA Rating 1, 12, 13, IP Rating IP66, IP67, Operating Temp. Range -13 Degrees to 185 Degrees F, Contact Material Silver, Cable Length 9.8 ft, Body Material Plastic
