Gas Pressure Regulator with Solenoid Valve, 1-1/2" NPT, 24V DC
Mfr # KS88018096
Zoro # G115390536
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER REG,PRSS RED,1 1/2NPT,GAS W/SOL VAD2T40N is a pressure regulator intended for use in applications involving control and monitoring of gas pressure. It integrates a solenoid valve and is compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. This unit features a maximum inlet pressure of 500 mbar (7 psig) and an outlet pressure range of 35-100 mbar. The device comes equipped with a pilot lamp for status indication and offers electrical connection via an M20 cable gland.
Key features include:
- Class A pressure regulator to EN 88 standard
- Class A solenoid valve to EN 161 standard
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet: DN 15 (1/2") Rp internal thread; no inlet flange
- Features rapid actuation mechanism
- IP65 rated enclosure
- FM and SA approved; EU certified
- Mains voltage: 24 V DC
- Electrical connection: M20 cable gland attached on the right side of the connection box
- Valve seat reduced design with optional accessories such as right-side pressure switch (30–110 mbar) and left-side screw plugs
Restrictions
