Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD3-/50R/NP-50A is a pressure regulator intended for use in applications involving gas pressure regulation. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane. It features an outlet with DN 15 (1/2") Rp internal thread, operates at a maximum inlet pressure of 500 mbar (7 psig), and is rated for an outlet pressure range of 35 to 100 mbar.

Key features include:

• Integrated pilot lamp for status indication
• Electrical connection via M20 cable gland; mains voltage: 24 V DC
• IP65 rated enclosure
• FM and SA approved; EU certified
• Features rapid actuation mechanism
• No inlet flange; size 1 configuration
• Valve seat reduced design
• Right-side accessory port supports a pressure switch (30–110 mbar) with test point on outlet side; left side includes two screw plugs
