Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD125R/NW-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit features a Class A pressure regulator to EN 88 standards and incorporates a Class A solenoid valve to EN 161, suitable for use with gas, air, and biologically produced methane. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar.

Key features include:

• Pilot lamp indicator
• IP65 rated enclosure
• FM and SA approvals; EU certified
• Outlet: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced design with right-side accessory options including a pressure switch (30–110 mbar) and test point for outlet pressure; left side includes two screw plugs Features rapid actuation mechanism
