Gas Pressure Regulator with Solenoid Valve, 24V DC, DN15, IP65 Rated

The HONEYWELL KROMSCHRODER VAD250/40R/NW-50A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it suitable for use with gas, air, and biologically produced methane as specified. It operates at a maximum inlet pressure of 500 mbar (7 psig) and features an outlet with DN 15 (1/2'') Rp internal thread connection.

Key features include:

• Integrated pilot lamp for operational status indication
• IP65-rated enclosure for protection against dust and water ingress
• FM and SA approvals; EU certified
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on the right side of the connection box
• Outlet pressure range: 35–100 mbar; reduced valve seat design
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left-side two screw plugs
• No inlet flange
