Gas Pressure Regulator with Solenoid Valve, 35-100 mbar, DN15, 24V DC

The HONEYWELL KROMSCHRODER VAD350R/NW-100A is a pressure regulator intended for use in the control and regulation of gas pressure in industrial systems. It meets Class A standards to EN 88 and features an integrated solenoid valve compliant with EN 161, suitable for use with gas, air, and biologically produced methane. The unit operates at a maximum inlet pressure of 500 mbar (7 psig) and is rated for outlet pressures within the range of 35 to 100 mbar.

Key features include:

• Integrated pilot lamp for status indication
• IP65 enclosure rating
• FM and SA approvals; EU certified
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced design; size 1 configuration
• Right-side accessory port supports a pressure switch (30–110 mbar) with test point at outlet pressure; left side includes two screw plugs
