Gas Pressure Regulator with Solenoid Valve, 500 mbar, DN15, 24V DC

The HONEYWELL KROMSCHRODER VAD3-/50R/NW-50A is a pressure regulator intended for regulation and control of gas pressure within compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified. It features an integrated pilot lamp, rapid actuation mechanism, and electrical connection via M20 cable gland.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Protection rating: IP65
• Approvals: FM and SA approved; EU certified
• Mains voltage: 24 V DC
• No inlet flange; size 1 configuration
• Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side, left-side screw plugs
