Gas Pressure Switch, 3–500 mbar, DG Series, UL/CE/FM

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 60VC4 6W is a gas pressure switch rated for use in applications requiring monitoring of positive gas pressures within the specified pressure range.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Electrical contacts: Silver or gold contacts available; CE version supports up to 250V AC and UL versions support up to 240V AC
• Switching capacity: Up to 5A depending on contact type
• Electrical connection via a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved, EAC marked These switches are compatible with gases including natural gas, biogas, air, and flue gases as per manufacturer specifications. Provides switching point adjustment through a setting dial or factory preset options according to product design.
