Gas Pressure Switch - 3–500 mbar, DG..C Series, UL/FM/AGA

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 40VC6D 6WG is a gas pressure switch rated for monitoring positive pressure within the specified media (gases, biogas, air, and flue gases) as per product specifications. It utilizes a diaphragm mechanism with a micro switch that does not contain silicone. This device is intended for applications requiring gas pressure monitoring within the stated parameters.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Switching point adjustment via setting dial or factory set
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or 1/4)
• Electrical connection: 4-pin plug and socket
• Contact options: Silver contacts (24–250V AC, 0.05–5A) and gold contacts (5–250V AC, 0.01–5A) for CE version; gold contacts (max 30V AC, 0.05A) and silver contacts (30–240V AC, up to 5A) for UL versions
• Certified by EU, UL listed, FM approved, AGA approved
• RoHS compliant design
