Gas Pressure Switch, Adjustable, DG Series, Air/Gas/Flue

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 12IG 4 is a gas pressure switch rated for use with positive gas and air pressures, as well as negative and differential air pressures within specified parameters. This device includes an adjustable switching point controlled by a setting dial and operates with media such as gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions to accommodate different regional standards.

Key features:

• Includes an adjustable switching point controlled by a setting dial
• Compatible with gas, air, and flue gases under the specified operating conditions
• Available in European (DG) version: EU certified, AGA/EAC approved; range of 0.4 to 500 mbar (0.16 to 200 "WC); internal Rp 1/8" or Rp 1/4" pneumatic connections; silver contacts rated at 24–250V AC, gold contacts at 5–250V AC
• Available in US (DG..T) version: UL Listed/FM Approved; range of 0.2 to 200" WC; internal NPT pneumatic connections; silver contacts up to max 240V AC/5A, gold contacts up to max 30V AC/DC/0.05A
• Electrical connection options include screw terminals with M16x1.5 cable gland or conduit entry, and a four-pin plug/socket
