Gas Pressure Switch - DG Series, 3-500 mbar, Silicone-Free

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 17VC5 6W is a gas pressure switch rated for monitoring positive gas pressures within the specified pressure range. It utilizes a diaphragm mechanism with a micro switch that does not contain silicone, making it compatible with gases including natural gas, biogas, air, and flue gases according to manufacturer specifications. The unit features an adjustable switching point via external setting dial or available as a factory-set option.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal Rp 1/4 (single or dual), External Rp 1/8 or Rp 1/4
• Electrical contacts: Silver and gold options available; supports voltages from 5V to 250V AC depending on version
• Switching capacity: Up to 5A depending on contact type and certification
• Certifications: EU certified, UL listed, FM approved, AGA approved, EAC marked
• Electrical connection via a four-pin plug and socket
• Silicone-free construction
