Gas Solenoid Valve - 500 mbar, Class A, IP65, SIL 3

The HONEYWELL KROMSCHRODER VAS125R/NWGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates according to EN 161 standards; valve is closed when de-energized. The unit rated for a maximum operating pressure of 500 mbar and includes features such as pilot lamp and flow adjustment. This model is certified to meet SIL 3 and PL e requirements, with approvals from FM and CSA, as well as EU certification.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• IP65 rated enclosure
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
