Gas Solenoid Valve - 500 mbar, IP65, Class A, VAS Series

The HONEYWELL KROMSCHRODER VAS780F05LWGR3B/MM/MM is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This unit remains closed when not energized, and supports a maximum operating pressure of 500 mbar. It includes a pilot lamp and adjustable flow settings, is rated IP65 for ingress protection, and is certified to applicable EU, FM, and CSA standards. The product is suitable for installation in systems with requirements up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick-opening/closing or slow-opening/quick-closing operation types
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator/visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
