Gas Solenoid Valve – 500 mbar, IP65, Class A, VAS Series

The HONEYWELL KROMSCHRODER VAS780F05LW3B/P2/MM is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. When not energized, the valve is in a closed position and operates at a maximum pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and is rated to IP65 for ingress protection. The unit holds EU certification as well as FM and CSA approvals, with certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
