Gas Solenoid Valve - 500 mbar, IP65, EN 161, SIL 3 Rated

The HONEYWELL KROMSCHRODER VAS 665F05NW3B/MM/PP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It meets the requirements of EN 161 standards, remains closed when not energized, and is rated for a maximum operating pressure of 500 mbar. This model includes a pilot lamp and flow adjustment feature, has an IP65 ingress protection rating, and is certified to applicable EU, FM, and CSA standards. The valve is certified according to SIL 3 and PL e system requirements.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
