Gas Solenoid Valve - 500 mbar, IP65, EN161, Class A

The HONEYWELL KROMSCHRODER VAS665F05NK3E/PP/B is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air. It is rated to meet EN 161 standards and configured to remain closed when de-energized. This model has a maximum operating pressure rating of 500 mbar and features include pilot lamp and flow adjustment. The unit has an IP65 rating for ingress protection and is certified under EU, FM, and CSA approval schemes. It is certified according to SIL 3 and PL e requirements.

Key features:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
