Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Compliant

The HONEYWELL KROMSCHRODER VAS240F/LQSR is a Class A solenoid valve intended for use in systems requiring automatic shut-off of gas and air. It compliant with EN 161 standards, remains in the closed position when not energized, and supports a maximum operating pressure of 500 mbar. The unit includes pilot lamp indicator and adjustable flow settings, with an IP65 rating for ingress protection. This model holds certifications from EU, FM, and CSA and is suitable for installation in systems with requirements up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator (visual), fitted bypass or pilot gas valve, and integrated pressure switches DG../VC
