Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS120/-R/LK is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. This unit meets the requirements of EN 161 standards and is normally closed when de-energized. It is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment options. The valve is rated to IP65, carries EU certification, FM and CSA approvals, and is certified as meeting SIL 3 and PL e performance levels.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing operation: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
