Gas Solenoid Valve – Class A, EN 161, 500 mbar, IP65

The HONEYWELL KROMSCHRODER VAS110R/NWGL is a Class A solenoid valve conforming to EN 161 standards. It is intended for use in automatic shut-off applications involving gas and air. The valve is configured to be in a closed position when not energized and includes a pilot lamp and adjustable flow settings. It is rated for a maximum operating pressure of 500 mbar and carries IP65 ingress protection. The unit holds EU certification as well as FM and CSA approvals, with compatibility with systems requiring SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
