Gas Solenoid Valve - VAS2, 500 mbar, IP65, Threaded/Flanged, Class A

The HONEYWELL KROMSCHRODER VAS2-/40R/LWSR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. The valve is configured to be in a closed position when not energized and supports a maximum operating pressure of 500 mbar. It is equipped with a pilot lamp, adjustable flow mechanism, and has an ingress protection rating of IP65. The unit holds certifications under applicable EU standards, FM, and CSA approvals, with suitability for systems that require compliance with SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
