Gas Solenoid Valve - VCS Series, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VCS665F05NNWL3B/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. The valve is configured to be in a closed position when not energized and supports a maximum operating pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and offers protection rated at IP65. The valve meets EN 161 standards and holds EU certification as well as FM and CSA approvals. It is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: provides options for actuation speed as specified
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
