Solenoid Gas Safety Valve - 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VCS780F05NNWL3E/PPPP/PPEP is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve is configured to be closed when not energized and supports a maximum operating pressure of 500 mbar. It includes an integrated pilot lamp and adjustable flow settings, and is rated to IP65 according to IEC standard 60529. The unit is certified according to applicable EU, FM, and CSA standards, with suitability for use in systems up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening & closing or slow opening & quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
