Solenoid Valve for Gas/Air – Class A, 500 mbar, IP65, VCS780F05NLWR3B

The HONEYWELL KROMSCHRODER VCS780F05NLWR3B/PPPP/2-P4 is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This valve operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. It includes an integrated pilot lamp and adjustable flow, with an IP65 rating for ingress protection. The unit is EU certified as well as FM and CSA approved, and it is compatible with systems requiring up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options include threaded or flanged
• Operation types are quick opening/quick closing or slow opening/quick closing
• Compatible mains voltages are 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided by terminal block
• Versions available with position indicator, visual indicator, fitted bypass/pilot gas valve, and/or fitted pressure switches
