Solenoid Gas Safety Valve - 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS225R/LW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. It operates with a maximum pressure of 500 mbar and has a closed position when not energized. The unit includes a pilot lamp, adjustable flow settings, and an IP65 rating for ingress protection. Certified to EN 161 standards, it holds EU certification as well as FM and CSA approvals, and is rated for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
