Solenoid Gas Safety Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS115/-R/NWGR is a Class A solenoid gas safety valve. It is intended for use in applications requiring automatic shut-off of gas and air lines. When de-energized, the valve is in a closed position and supports a maximum operating pressure of 500 mbar. It features flow adjustment, a pilot lamp, and an IP65-rated enclosure. This model meets EN 161 standards; holds EU certification as well as FM and CSA approvals. It is also certified as compliant with SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
