Solenoid Gas Safety Valve - Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS350F/LW is a Class A solenoid gas safety valve. It is intended for use as an automatic shut-off valve in gas and air systems. It operates according to EN 161 standards; the valve is closed when not energized, and supports a maximum operating pressure of 500 mbar. The unit includes an integrated pilot lamp, adjustable flow setting, and has an ingress protection rating of IP65. It holds EU certification as well as FM and CSA approvals, and is certified under SIL 3 and PL e classifications.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass or pilot gas valves, and fitted pressure switches DG../VC
