Solenoid Gas Safety Valve - VAS-VCS, 500 mbar, IP65, Class A Certified

The HONEYWELL KROMSCHRODER VAS2T32/-N/NQGL is a Class A solenoid gas safety valve. This valve operates with a closed position when de-energized. It is intended for use in applications requiring automatic shut-off and is rated for operation at pressures up to 500 mbar. It includes a pilot lamp, adjustable flow feature, and is IP65 rated for ingress protection. The unit meets EU certification standards as well as FM and CSA approvals, and it holds certification meeting requirements of SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
