Solenoid Valve for Gas, Class A, 500 mbar, IP65, EN 161 Compliant

The HONEYWELL KROMSCHRODER VAS115/-R/NK is a Class A solenoid valve conforming to EN 161 standards. This valve is intended for use in automatic shut-off applications for gas and air. The valve is configured to be closed when not energized and operates at a maximum pressure of 500 mbar. It features a pilot lamp, adjustable flow settings, and an IP65 rating for ingress protection. The unit holds EU certification as well as FM and CSA approvals, with compatibility with systems requiring SIL 3 or PL e compliance.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
