Solenoid Valve for Gas/Air, 500 mbar, Class A, IP65

The HONEYWELL KROMSCHRODER VAS1-0/15R/NQ is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This valve compliant with EN 161 standards, is normally closed when not energized, and is rated for maximum operating pressure of 500 mbar. It features a pilot lamp and flow adjustment capability, an IP65-rated enclosure, and carries EU certification as well as FM and CSA approvals. The unit is certified for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening characteristics: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
