Solenoid Valve for Gas/Air, 500 mbar, EN 161, IP65, Class A

The HONEYWELL KROMSCHRODER VAS8100F05LQB/PP/PP is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air. This unit compliant with EN 161 standards, remains closed when not energized. It supports a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment options. The product holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Valve sizes from 1 to 9; nominal diameters (DN) ranging from 10 to 125
• Available with threaded or flanged connections
• Quick opening/closing or slow opening/quick closing operation options
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• IP65 rated enclosure for ingress protection
• Versions available with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
