Solenoid Valve for Gas/Air, 500 mbar, IP65, Auto Shut-Off, VCS Series

The HONEYWELL KROMSCHRODER VCS8100F05NNWR3E/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit remains closed when not energized. It is rated for a maximum operating pressure of 500 mbar and equipped with pilot lamp and flow adjustment. The valve rated to IP65 ingress protection standard, holds EU certification, FM approval, and CSA approval, and is suitable for installation in systems classified up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN) from 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions may include position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches
