Solenoid Valve for Gas/Air, 500 mbar, IP65, EN 161 Class A

The HONEYWELL KROMSCHRODER VAS7T80A05LQSRE/3P/PP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit meets the requirements specified by EN 161 standards, is configured to be closed when not energized. It supports a maximum operating pressure of 500 mbar and includes both a pilot lamp and flow adjustment feature. The valve carries IP65 ingress protection, is EU certified, FM and CSA approved, and holds certifications for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator (visual), fitted bypass/pilot gas valve, or integrated pressure switches
