Solenoid Valve for Gas/Air, Class A, 500 mbar, EN 161, IP65 Rated
Mfr # KS88204170
Zoro # G315426141
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS7T80A05NNWSLE/PPVP/2-P3 is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air lines. This valve manufactured to meet the requirements of EN 161 standards, configured to remain closed when de-energized, and is rated for maximum operating pressure up to 500 mbar. It includes a pilot lamp and adjustable flow settings, an IP65-rated enclosure, and holds EU certification as well as FM and CSA approvals. The unit is certified according to SIL 3 or PL e system requirements.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation modes: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
